XMAX 125 Tech MAX
Yamaha’s XMAX 125 Tech MAX has just about everything you need to get around town in style and comfort. This high-quality sports scooter is designed to help you enjoy your urban commute to the fullest with its dynamic new aesthetic, best-in-class specifications and an accessible design focused on ease of use
Take a look
- Full color 4.2-inch TFT instrumentation
- Smartphone connectivity
- On-board navigation system via smartphone
- Dynamic body design
- Radical X-shaped headlight
- High-mounted front flashers
- Full LED lighting
- Seat remodeled and upholstered in imitation leather
- Space to store two full-face helmets
- EURO5 Blue Core 125cc engine
- Traction Control System (TCS)
- Keyless ignition via Smart Key
- Adjustable screen and handlebar
- Tech MAX Finish
- Specific Tech MAX colors
Follow the MAX
The hugely popular XMAX 125 Tech MAX is equipped with new generation 4.2-inch full color TFT instrumentation, including a multimedia display with smartphone connectivity. It’s easy to receive messages and emails, listen to your favorite music and much more, and the new Garmin navigation system will make your daily commute even easier.
The dynamic and compact angular body design, with its new X-shaped front lighting, gives the new XMAX 125 Tech MAX an even sportier look that sets it apart from the rest. In addition, this class-leading 125cc city scooter, along with exclusive colours, is equipped with aluminum footboards, a special finish on body parts and a leatherette-trimmed seat.
Technical specifications
Engine type: 4-stroke, Liquid-cooled, SOHC, 4-valve, Single cylinder
Displacement: 125 cc
Bore x Stroke: 52,0 × 58,7 mm
Compression ratio: 11.2:1
Maximum power: 9.0 kW and 8000 rpm
Maximum torque: 11,2 Nm a 6000 r.p.m.
Lubrication system: wet sump
Fuel system: Fuel injection
Ignition system: TC|
Starting system: Electric
Transmission system: Automatic V-belt
homologated consumption: Start & Stop activada: 2,3L/100km, con Start & Stop desactivado: 2,4L/100 km
CO2 emission: Start & Stop activated: 54 g/km, with Start & Stop deactivated: 56 g/km
Front suspension system: Telescopic fork
Front travel: 110 mm
Rear suspension system: oscillating unit
Rear travel: 90 mm
Front brake: Hydraulic single disc brake, Ø 267 mm
Rear brake: A Ø 245 mm hydraulic disc (ABS)
Front tire: 120/70-15
Rear tire: 140/70-14
Total length: 2180 mm
Total width: 795 mm
Total height: 1,410mm-1,460mm (adjustable windscreen)
Seat height: 800 mm
Distance between axis: 1,570 mm
Minimum ground clearance: 140 mm
Weight (including full oil tank and fuel tank): 167 kg
Fuel tank capacity: 13,2L
