Take a look
- Yamaha’s lightest scooter
- Blue Core 125cc EURO5 compliant engine
- Start & Stop function
- LED headlights and LCD instrumentation
- Combined braking system
- Storage space under the seat
- Comfortable riding position
- Dynamic motorcycle-style body design
- One-touch button start system
ENJOY WITH RAY.
You will be surprised to see everything this practical scooter can offer you! Its economical 125 cc Blue Core engine features a special Power Assist system for faster acceleration, and weighing just 99 kg, the RayZR moves with great agility through the bustle of urban traffic. It has a large cargo space to store your helmet* or go shopping. (*Depending on the shape of the helmet, some models may not fit in the recess under the seat.)
Its spacious two-seater seat guarantees a relaxed trip on every journey. The RayZR can be driven in many countries with a B** driving licence, and with Yamaha’s renowned reliability and extensive dealer network, peace of mind comes as standard. (**There may be limitations and restrictions depending on the country and applicable local laws. Additionally, Yamaha recommends that all users take a motorcycle riding course before riding any two- or three-wheeled vehicle.)
Technical specifications
Engine type: 4 stroke, SOHC, 2 valve, Air cooled
Displacement: 125cc
Bore x Stroke:52.4 × 57.9mm
Compression ratio:10.2:1
Maximum power: 6.0 kW at 6500 rpm
Maximum torque:9.7 Nm at 5000 rpm
Lubrication system: Wet sump
Fuel system: Fuel injection
Ignition system:TC|
Starting system: Electric starter motor and kick start mechanism
Transmission system: Automatic V-belt
Approved consumption: 1.8L/100km
CO2 emission:42g/km
Front suspension system: Telescopic forks
Front travel:90mm
Rear suspension system: Oscillating unit
Rear travel: 80mm
Front brake:A hydraulic disc brake
Rear brake: Mechanical drum brake
Front tire:90/90-12 tubeless
Rear tire:110/90-10 tubeless
Total length:1880mm
Total width: 685mm
Total height: 1190mm
Seat height:785mm
Distance between axis: 1280mm
Minimum ground clearance: 145mm
Weight (including full oil tank and fuel tank): 99kg
Fuel tank capacity: 5.2L
